Water Flow Control & Magnetic Flow Meter IPX1–IPX6

SKU ORTYFC529-120
Price

$2,595.00

Water flow control and magnetic flow measurement system for setting and recording test flow in IPX1 to IPX6 tests, per IEC 60529 clauses 14.2.1 to 14.2.6.

Standards

  • IEC 60529 – IPX1 to IPX6 flow requirements
  • ISO 20653

Technical data

MeasurementMagnetic-inductive flow meter
ApplicationIPX1, IPX2, IPX3, IPX4, IPX5, IPX6
WaterSoftened / demineralized
Power supply24 V DC, IP65 protected
Inlet / outlet3/4" / 1/2"
ControlManual ball valves or PLC + HMI (semi-automatic)

Ref.: DNFC529-120 (Dunel) / ORTYFC529-120 (Ormity) – former codes: ORTY0075/120

Versions

Quantity

Test Principle & Function

Flow control panel with magnetic-inductive flow meter for drip boxes, oscillating tubes, spray nozzles and jet nozzles. Manual control by ball valves, or semi-automatic control by PLC and HMI.

Versions & Order Codes

DNFC529-120A / ORTYFC529-120A Analogue control
DNFC529-120S / ORTYFC529-120S Semi-auto PLC + HMI

Ordering, Calibration & Warranty

  • Lead time: up to 35 days with Ormity factory calibration; up to 60 days with an ISO/IEC 17025 calibration report (charged separately).
  • Warranty: 1 year, plus lifetime warranty against non-compliance (excluding standard revisions published after the date of sale).
  • Payment: international orders are 100% prepaid. All sales are final after 30 days.
  • Shipping: by third-party international carriers; transit time depends on destination, packing (crate/pallet) and calibration route. Ask for a delivery estimate before ordering.
